디지털 Micro ohmmeter DO7e

* True 4 wire measurement eliminates lead resistance
* 6 push button ranges 60 milliohms to 600 ohms
* 측정분해능 : 1 microhm on 60 milliohm range
* Auto ranging
* 10 Amp measuring current on lowest range
* 0.8' LED Display daylight viewable
* Input protection up to 415 Volts rms
* Forward and reverse current measurement
* Auto average of forward and reverse measurement
* Auto power off
* Mains / rechargeable battery operation
* Ditgital calibration pass code protected

휴대용 Micro ohmmeter DO4A

* 10 micro ohm resolution on 40 milli ohm range
* Input protection up to 415 Volts rms
* Zero control thermal E.M.F. compensation
* Digital calibration
* Mains / rechargeable battery operation
* Open circuit lead warning
* Rugged industrial maintenance free design
* True 4 wire measurement eliminates lead resistance errors
* 6 push button ranges 40 milli ohm... 4 kilo ohm with long scale length
* Universal mains supply 100 / 200 / 220/ 240 Volts +10% - 13%

휴대용 Milliohmmeter 4000 Series

* True 4 wire measurement eliminates lead resistance errors
* 6 ranges 40 milliohms to 4 kilohms, long scale length
* 4000 count. Automatic or manual range selection
* Input protection up to 415 Volts rms
* Resolution 10 microhms on 40 milliohm range
* Forward and reverse current measurement with auto average
* True current Zero
* Temperature compensation Model 4001
* Temperature Measurement -50...+800 Deg.C Model 4001
* Digital calibration
* Mains / rechargeable battery operation
* Open circuit lead warning
* Rugged industrial and maintenance free design
* Rechargeable battery option

휴대용 Micro ohmmeter DO7010

* True 4 wire measurement eliminates lead resistance errors
* 4 ranges 6 millohms to 6 ohms
* Resolution 1 microhm on 6 millohm range
* Graphics Display with backlight 3 languages
* 1 and 10 Amp measuring current even on the 600milliohm range
* Forward and reverse current measurement
* Auto average of forward and reverse measurement
* True zero offset
* Built in test resistor for confidence check
* Data logging with up to 1000 readings stored with date and time stamp.
* Hi-Lo limits with audible and visual warning
* Automatic measurement trigger when leads are connected to DUT
* Small size and light weight <4Kg
* RS232 interface with option remote terminal to enable operation up to 15 metres distance.
* Rechargeable NiMhd batteries with charge indicator and easily replacable battery pack

디지털 Micro ohmmeter DO7

* True 4 wire measurement eliminates lead resistance
* 6 push button ranges 600 microhms to 60 ohms
* Resolution 0.1 microhm on 600 microhm range
* 0.8' LED Display daylight viewable
* 10 Amp measuring current on lowest range
* Forward and reverse current measurement
* Auto average of forward and reverse measurement
* Input protection up to 415 Volts rms
* Printer output and remote start
* Digital calibration key protected
* Mains / rechargeable batteries with charge indicator and built in charger

디지털 Microhmmeter DO7 Plus

* On screen real time graphical plotting cooling curve facilities with peak resistance value calculator
* It's fast, reading rate of 2 readings per second
* 측정범위 : 6 mohm to 6 Kohm
* 측정분해능 : 100 nohm to 6 mohm range
* 밧데리 절전용 LCD지시부와 프로그램 Timer
* Single pulse measurement for fast resistance tests
* Continuous measurement current for inductive tests
* Full test lead continuity testing and diagnostic display

디지털 Microhmmeter DO5000 Series

* True 4 measurement eliminates lead resistance errors
* Wide measuringe range 3 milliohms to 30 kilohms
* Resolution 0.1 microhms on 30 milliohm range
* High accuracy 0.03%
* Programmable measuring currents 0 to 100% in 1% steps
* 10 Amp measuring current
* Programmable Hi/Lo limits with red/green lamps on front panel
* Fast measuring mode up to 50 measurements / second
* Automatic temperature compensation with programmable oefficients
* Open circuit limit mode 20mV / 50mV maximum
* Measuring current +I -I and auto average
* Interface options RS232, IEEE-488 and PLC
* Data logging with statistical analysis
* Rechargeable battery version
* Calculates cable length ohms/kilometre

디지털 변압기 권선 Microohmmeter

* True 4 measurement eliminates lead resistance errors
* Wide measuringe range 2 milliohms to 2 kilohms
* Resolution 0.1 microhms on 2 milliohm range
* High accuracy 0.25% rdg + 0.25% fs
* 2 channel measurement for primary and secondary windings
* Data logging with large colour alpha numeric storage for test results
* Robust power supply for fast testing of large power transformers
* Open circuit limit mode 20mV / 50mV maximum
* Interface RS232 and USB
