HT9021

HT9021 professional clamp is designed for DC/AC TRMS current measurement up to 1000A, and DC/AC voltage for achieve safety CAT IV 1000V according to IEC/EN61010-1 safety standard. The model have a large LCD 4 digit display (6000counts), with backlight and bargraph to more easy reading in critical environments. The model perform also resistance, continuity test, frequency, capacitance, diode test, duty cycle and temperature with type K probe measurements. The AutopowerOFF feature is also available for the meter in order to preserve it’s internal battery charge

HT9019

HT9019 professional clamp is designed for AC TRMS current measurement up to 1000A, and DC/AC voltage for achieve safety CAT IV 1000V according to IEC/EN61010-1 safety standard. The model have a large LCD 4 digit display (6000counts), with backlight and bargraph to more easy reading in critical environments. The model perform also resistance and continuity test measurements. The AutopowerOFF feature is also available for the meter in order to preserve it’s internal battery charge

HT9015

HT9015 professional clamp is designed for DC/AC TRMS current measurement up to 600A, and DC/AC voltage for achieve safety CAT IV 1000V according to IEC/EN61010-1 safety standard. The model have a large LCD 4 digit display (6000counts), with backlight and bargraph to more easy reading in critical environments. The model perform also resistance, continuity test, frequency, capacitance, diode test, duty cycle and temperature with type K probe measurements. The AutopowerOFF feature is also available for the meter in order to preserve it’s internal battery charge

HT9014

HT9014 professional clamp is designed for AC TRMS current measurement up to 600A, and DC/AC voltage for achieve safety CAT IV 1000V according to IEC/EN61010-1 safety standard. The model have a large LCD 4 digit display (6000counts), with backlight and bargraph to more easy reading in critical environments. The model perform also resistance, continuity test, frequency, capacitance, diode test, duty cycle and temperature with type K probe measurements. The AutopowerOFF feature is also available for the meter in order to preserve it’s internal battery charge

HT9012

HT9012 professional clamp is designed for AC current measurement up to 600A, and DC/AC voltage for achieve safety CAT IV 600V according to IEC/EN61010-1 safety standard. The model have a LCD display with backlight to more easy reading in critical environments. The model perform also resistance and continuity test measurements. The AutopowerOFF feature is also available for the meter in order to preserve it’s internal battery charge

HT78

The innovative HT78 clamp is a meter for accurate measurement of very low AC TRMS current values (from 0.1mA) and it’s ok for leakage current measurements in civil and industrial electrical installations to solve typical problem of RCDs accidentally tripping. The integrated low pass filter permits the cut of high order harmonics and the analogical DCV output permits a connection with external data loggers. The meter permits to measure up to 3000A and, thanks to large jaws, clamp cables and/or bars of wide sizes. The meter is compliance to IEC/EN61010-1 safety standard in CAT II 600V, CAT III 300V

HT77N

The innovative model HT77N is a clamp meter for accurate measurements of very low AC current values. It is mainly employed in measuring leakage currents causing typical problem of RCDs accidental tripping on civil and industrial electrical installations. The built-in 100Hz low pass filter permits to cut off harmonic components. Some alarm thresholds can be selected on HT77N with acoustic indications depending on the measured current values. It is also provided with a sophisticated automatic backlight sensor to perform testing in dark environments. The meter complies with IEC/EN61010-1 safety standards under CAT III 300

HT7019

HT7019 professional clamp is designed for AC TRMS current measurement up to 1000A, DC voltage up to 1000V for achieve safety CAT III 1000V according to IEC/EN61010-1 standard. The model have a large LCD 3 ¾ display (4000counts), with backlight and analogic bargraph to more easy reading in critical environments. Each of this functions can be performed with a rotative selector at 8 positions, included the key for enable Data HOLD function. HT7019 clamp have a Auto Power Off function to preserve the internal battery and it is possible to clamp-on a conductor with maximum size of 51 mm. There are added the following functions also: MIN, MAX, PEAK for minimum, maximum and peak value measurements

HT7016

HT7016 professional clamp is designed for AC current measurement up to 1000A, voltage DC voltage up to 1000 V for achieve safety CAT III 1000 V according to IEC/EN61010-1 standard. The model have a large LCD 3¾ digit display (4000counts), with backlight and analogic bargraph to more easy reading in critical environments. Each of this functions can be performed with a 6 positions selector, included the key for enable Data HOLD function. HT7016 clamp have a AutoPowerOff function to preserve the internal battery and it is possible to clamp-on a conductor with maximum size of 51 mm. There are added the following functions also: MIN, MAX, PEAK for measurement of minimum, maximum and peak values

HT7015

HT7015 professional clamp it's a TRMS instrument designed AC current measurement up to 600A for achieve safety CAT III 600V according to IEC/EN61010-1 standard. The model have a large LCD 3¾ display (4000counts), with backlight and bargraph to more easy reading in critical environments. Each of this functions can be performed with a rotative selector at 8 positions, included the key for enable Data HOLD function. HT7015 clamp have a AutoPowerOff function to preserve the internal battery and it is possible to clamp-on a conductor with maximum size of 35 mm. There are added the following functions also: MIN, MAX, PEAK and ZERO for of minimum, maximum and peak value measurements and for relative measurements

HT7012

HT7012 clamp is designed for AC current measurements up to 600A for achieve safety CAT III 600V according to IEC/EN61010-1 safety standard. The meter have a large LCD 3¾ LCD display (4000 counts) with backlight and bargraph to more easy reading in critical environments. Each of this functions can be performed with a 6 positions selector, included the key Data HOLD function. HT7012 have a AutoPowerOff feature to preserve the internal battery and it is possible to clamp-on a conductor with maximum size of 34mm. There are added other functions like MIN, MAX and PEAK for minimum, maximum and peak measurement value for each parameter

HT7011

HT7011 model it's a innovative meter designed for AC Current measurement up to 200A which use a "open clamp" technology where it's no necessary open jaws but simply the cable can be fitted in the relative section present on the top part of meter. This way permits to performing quickly and flexible measurements on current measurements. HT7011 clamp have also a integrated sensor (VoltSense) for detection voltage presence with or without directly contact with point on test. The meter performs DC/AC Voltage measures with double insulation in CAT IV 600V and CAT III 1000V overvoltage categories according to EN 61010-1 safety standard. Resistance, Continuity test with buzzer and Diode test are also available measurements. Each functions can be selected with a rotative selector included a key for enable HOLD feature. The extreme easy to use permits to HT7011 to be ideal for any electrical installer

HT4022

HT4022 is a clamp meter that performs TRMS measurement of AC current up to 400A, AC/DC voltage, frequency, resistance and continuity. This model also perform measures of Active, Reactive, Apparent power, Power Factor (cosphi), Energy, Voltage/Current harmonics, both in single phase and three phase systems and have a patented phase rotation measures with an innovative one wire method. Thanks to the practical rubber cap to be mounted on the jaws (patented also), it's possible to hold test leads while measuring and have one hand free to work. The large 4 digit LCD display (10000 counts) with backlight permits an easy readability also in critical visual conditions. The instrument is complying with IEC/EN61010-1, CAT III 600V and is ideal to solve typical problems occurring in industrial environments such as troubleshooting, non-linear loads, frequency driven motors, PCs

HT4020

HT4020 is a clamp meter that performs TRMS measurement of AC current up to 400A, AC/DC voltage, frequency, resistance and continuity. This model also perform measurements of Active, Reactive, Apparent power, Power Factor (cosj) and Energy, both in single phase and three phase systems and have a patented phase rotation measures with an innovative 1 wire method. Thanks to the practical rubber cap to be mounted on the jaws (patented also), it's possible to hold test leads while measuring and have one hand free to work. The large 4 digit LCD display (10000 counts) with backlight permits an easy readability also in critical visual conditions. The instrument is complying with IEC/EN 61010-1, CAT III 600V and is ideal to solve typical problems occurring in industrial environments such as troubleshooting, non-linear loads, frequency driven motors, PCs

HT4014

HT4014 clamp meter measure AC current up to 400A completely in Autorange, AC/DC voltage, resistance, frequency and continuity. Thanks to the practical rubber cap to be mounted on the jaws (patented), it's possible to hold test leads while measuring and have one hand free to work. The large 3 ¾ LCD display (4000 counts) with backlight and analogue bargraph permits an easy readability also in critical visual conditions. The instrument is complying with IEC/EN61010-1, CAT III 600V and is ideal for simple measurements both in domestic and industrial environments
